EL-WIFI-T WiFi Temperature Logger
$206.00
EL-WIFI-T WiFi-enabled Temperature data logger can remotely monitor an environment over a -20 to +60°C (-4 to +140°F) measurement range. Data is uploaded periodically using a standard WiFi network to the EasyLog Cloud or a single host PC.
- Description
- Specification
- Downloads
- Application
- Video Introduction
Description
EL-WIFI-T WiFi Temperature Data Logger
EL-WiFi-T Wifi Temperature Logger or temperature sensor by Lascar Electronics. This sensor measures the temperature of the environment in any location. It is also accurate to ±0.7˚C. Recorded data is streamed wirelessly over any WiFi network. It also can be viewed on a PC using our free Easylog Wifi Software or on the Easylog Cloud.
During configuration, the sensor will search for a wireless network while being connected to a PC. The sensor can now be placed anywhere within range of the network. If the sensor temporarily loses connectivity, it will continue to log readings until it regains its connection. It has to connect back to Easylog Wifi Software or the Easylog Cloud. The temperature sensor has a max of 120 days at a 10-second sample interval. EL-WiFi sensors have an impressive range which can be increased by using WiFi extenders.
The EL-WiFi-T is a low-powered battery device. When configured using typical transmission periods (e.g. once every 5 minutes) the sensor will operate for over one year (at room temperature). The battery can then be recharged via a PC or USB +5V wall adapter using the USB lead provided or can be permanently powered by the USB wall adapter. The software installed on the PC will allow set-up, data logging, and data review. Set-up features will include sensor name, °C/°F, sample rate, and high/low alarms. Once configured, historic data can be viewed via the graphing tool or exported into Excel. This software is available to download for free.
EL-WIFI-T Wifi Temperature Data Logger is a freestanding unit. However, users can also attach it to a wall or a vertical surface using the bracket and screws provided. A sticky pad will also be provided.
Specification
| Measurement Range | -20 to +60°C / -4 to +140°F) |
| Accuracy | ±0.5°C / ±1°F |
| Readings | Unlimited |
| Logging Rate | User selectable between 10 seconds and 12 hours |
| Calibration Certificate | Available Seperately |
| Battery | Rechargeable Battery / 6 Months Battery Life / Mains Powered Option |
Application
EL-WiFi-T Temperature Data Logger is suitable for a range of applications, which include temperature monitoring of Facilities Management, Housing & Business Premises and, Veterinary & Animal Welfare.
