EL-GFX-VAC2 Dual Channel Vaccine Monitoring Kit


The EL-GFX-VAC2 is a vaccine monitoring kit combining a USB dual channel data logger, two glycol bottle probes, and a calibration certificate. It has user-programmable audible alarm thresholds with highly visible confidence/alarm LEDs.

Availability: Available on backorder SKU: EL-GFX-VAC2 Categories: , , , , ,
View cart


EL-GFX-VAC2 Dual Channel GFX Vaccine Monitoring Kit

The EL-GFX-VAC2 is a vaccine monitoring kit by Lascar Electronics. It combines a USB dual channel data logger with two glycol bottle probes to create EL-GFX-VAC2.

The data logger is also able to store over 250,000 readings. It also comes with an on-screen display showing max, min, and last log. There is also an on-board graph of the data collected.

Buttons also allow users to start, stop and restart the logger during use. There are also alarm breaches that can be registered with both LED lights and an audible alarm. The data logger can also be battery-powered or used with a USB wall adaptor. Which gives it a longer battery life.

The two channels on the data logger allow the measurement of two areas. This could be of a refrigerator or a refrigerator and freezer at the same time. This vaccine data logger also meets and exceeds CDC standards for vaccine monitoring.

Here are just some of the resources of the EL-GFX-VAC 2.


Measurement Range
-40 to 60°C (-40 to 140°F)
±0.1°C (±0.2°F)
Operating temperature
-10 to 40°C (14 to 104°F)
Logging Rate
User selectable between 2 seconds and 1 hour
Calibration Certificate
Supplied at 2 and 8°C


Vaccine Monitoring Data Logger EL-GFX-VAC2 is a great tool to have due to its variety of applications. Such as, Vaccine Storage, Blood Storage, and Pharmaceutical Cold Chain monitoring.

Video Introduction
