EL-USB-ULT-LCD Ultra Low Temperature Logger
$231.00
This standalone data logger measures and stores up to 32,510 Carbon Monoxide (CO) readings over a 0 to 300ppm measurement range and -10 to +40°C (14 to +104ºF) operating temperature range. The user can easily set up the logging rate and start time and download the stored data by plugging the data logger into a PC’s USB port and running the purpose-designed software under Windows. The data can then be graphed, printed, and exported to other applications. The data logger is supplied complete with a long-life lithium battery. Data is stored in non-volatile memory and is retained when the battery is empty. A bright red LED will flash and a buzzer can sound when a preset warning level has been exceeded.
- Description
- Specifications
- Brochure
- Application
- Video Introduction
Description
EL-USB-ULT-LCD Ultra Low Temperature Data Logger with Display
EL-USB-ULT-LCD ultra-low temperature data logger by Lascar Electronics. It is designed for monitoring vaccines in cryogenic dry ice storage. The measurement range is -100 to +100°C using the probe supplied with the logger.
The logger can record over 32,000 readings and is simple to set up. It uses the free EasyLog software, which allows users to set their own high and low alarm thresholds. With alarm hold and delayed start features.
Flashing lights alert users to any temperature excursions. Just plug the logger into your PC’s USB port to download data. Which can then be graphed, printed, and exported to other applications for detailed analysis.
In conclusion, the EL-USB-ULT-LCD would be a great addition to your instruments. This data logger would come in handy when carbon monoxide monitoring is required. If you have any further questions, feel free to contact us! Or view Lascar Electronic’s EL-USB Data Logger series.
You are welcome to view the EL-USB-ULT-LCD Datasheet, EasyLog USB Software, EL-USB Quick Start Guide, EL-USB Range Troubleshooting, Tutorial Videos, EL-USB-ULT Declaration of Conformity.
Specifications
| Measurement range | -100 to +100°C |
| Accuracy (overall error) | ±2.5°C typical |
| Long term stability | <0.02°C (0.04°F) / year |
| Internal resolution | 0.5°C |
| Readings | 32,510 |
| Operating temperature (logger only) | -10 to +40°C |
| Dimensions (logger) | 118 x 27 x 27mm (4.6 x 1.1 x 1.1”) |
| Dimensions (probe) | 300 x Ø1.5mm x 1m cable (11.8 x Ø0.06" x 39.4" cable) |
| Battery Life | 2 Years |
| Logging Rate | User selectable between 10 seconds and 12 hours |
| Calibration Certificate | Available Separately |
Brochure
Application
The EL-USB-ULT-LCD ultra-low temperature data logger is designed for monitoring vaccines in cryogenic dry ice storage and transit. This includes Ultra Low-Temperature Vaccine Storage, Vaccine Storage, and Pharmaceutical Cold Chain.
