Testo Saveris 2-T3 WiFi Data Logger with Probe
$502.00
The testo Saveris 2 WiFi data logger system is the easy, versatile and reliable solution for the measurement and monitoring of temperature values in processes or in your storage, refrigerated and work rooms. Installing the system is child’s play and can be carried out via a browser.
- Description
- How It Works
- Testo Cloud
- Advantages
- Specification
- Downloads
- Delivery Scope
- Video
Description
Testo Saveris 2-T3 WiFi Data Logger and 2 Wide Range Temperature Probes
The WiFi data logger testo Saveris 2-T3 allows you to monitor the temperatures in processes or in refrigerated and work- or storerooms. The temperature values measured with the connectable thermocouple probes (TC) are reliably recorded over long periods, and transmitted directly to the Testo Cloud (online data storage) via your WiFi. You can access these readings at any time, anywhere, using your internet-enabled smartphone, tablet, or PC.
- A broad measuring range of -195 to +1350 °C is possible thanks to connectable probes (optional)
- WiFI data logger system with easy installation and operation
- Call up measurement data at any time via Smartphone, tablet, or PC
- Limit value violation alarms by e-mail or (optionally) SMS
How It Works
The temperature monitoring system consists of at least one WiFi data logger and a Cloud access (online data store). As a component of this data logger system, the testo Saveris 2-T3 data logger with up to 2 connectable thermocouple temperature probes (TC Types K, T, J) stores all measured temperature values and transmits them directly via your WLAN to the Testo Cloud. A broad measuring range of -200 to +1350 °C is possible thanks to the connectable TC probes. You can use the alarm function to receive immediate warnings by e-mail or SMS (optional) when limit values are violated.
Testo Cloud
The Testo Cloud is the core operating element for setting up your testo Saveris 2 system. Here you can configure your WiFi data loggers, set limit value alarms and analyze your measurement data. You can access all measuring values and analysis functions anywhere and at any time with an internet-capable smartphone, tablet or PC. You must first register at www.saveris.net to have access to the Testo Cloud.
Advantages
Current measuring values, limit value violations and the remaining battery life can be seen in the data logger’s display. The standard batteries (AA) have a lifetime of 12 months and can be replaced at any time by users themselves. The internal data memory of the WiFi data logger has a capacity of 2 x 10,000 readings and the housing is protected according to IP54.
Hint:
In order to use the testo Saveris 2-T3 WiFi data logger, you also require at least one connectable thermocouple probe (optional).
Hint:
In order to use the testo Saveris 2-T2 WiFi data logger, you also require at least one connectable probe (optional).
Specification
| Temperature - TC Type K (NiCr-Ni) | |
|---|---|
| Measuring range | -195 to +1350 °C |
| Accuracy | ±(0.5 + 0.5 % of mv) °C |
| Accuracy | 0.1 °C |
| Temperature - TC Type J (Fe-CuNi) | |
| Measuring range | -100 to +750 °C |
| Measuring range | ±(0.5 + 0.5 % of mv) °C |
| Accuracy | 0.1 °C |
| Temperature - TC Type T (Cu-CuNi) | |
| Measuring range | -200 to +400 °C |
| Accuracy | ±(0.5 + 0.5 % of mv) °C |
| Resolution | 0.1 °C |
| General technical data | |
| Weight | 240g |
| Dimensions | 95 x 75 x 30.5 mm |
| Operating temperature | -30 to +50 °C |
| Protection class | IP54 |
| Measuring rate | Dependent on Cloud licence; Basic: 15 min … 24 h / Advanced: 1 min … 24 h |
| Door contact | Yes |
| Communication rate | Dependent on Cloud licence; Basic: 15 min … 24 h / Advanced: 1 min … 24 h |
| WLAN Connectivity | Signal transmission: wireless, frequency band: 2.4 GHz, supported wireless LAN standards: IEEE 802.11 b/g/n and IEEE 802.1X; Possible encryption methods: without encryption, WEP, WPA, WPA2, WPA2 Enterprise - The data loggers communicate via the standard protocol MQTT and are SNTP time synchronization-capable. |
| Standards | DIN EN 12830 |
| Power supply | 4 x AA AlMn batteries; mains unit optional; for temperatures below -10 °C please use Energizer batteries 0515 0572 |
| Memory | 10,000 measurement values / channel |
| Battery life | 12 months (typical value, depending on the wireless LAN infrastructure) at +25 °C, 15-minute measuring cycle and standard communication cycle at -30 °C, 15-minute measuring cycle and standard communication cycle with Energizer batteries 0515 0572 |
| Storage temperature | -40 to +70 °C (without batteries) |
Downloads
Delivery Scope
- testo Saveris 2-T3 WiFi data logger
- Including free Cloud access (basic functionality)
- Micro USB cable
- Wall bracket with lock
- Batteries (4 x AA AlMn Mignon batteries)
- Short instructions
- Calibration protocol
- In order to use the testo Saveris 2-T3 WiFi data logger, you also require at least one connectable thermocouple probe (optional).
