EL-GFX-DTC Dual Thermocouple Data Logger


EL-GFX-DTC Dual Thermocouple Data Logger is a versatile data logger that is compatible with various thermocouples to personalize each user’s experience. EL GFX DTC Dual Thermocouple Data Logger is also able to record up to 250,000 temperature readings and provides a user-programmable audible alarm.

Availability: Available on backorder SKU: EL-GFX-DTC Categories: , , , , ,
View cart


EL-GFX-DTC Dual Channel Thermocouple Data Logger

EL-GFX-DTC is a Dual Thermocouple Data Logger by Lascar Electronics. This data logger records over 250,000 temperature readings per channel in one or more sessions for up to 4 months. It also comes with user-programmable audible alarm thresholds with highly visible alarm LEDs. EL-GFX-DTC is also compatible with K, J, and T-type thermocouples.

Inside the rugged case, buttons for start, stop, and restart and a graphic LCD with on-screen menus provide real-time analysis of data as a summary or as a graph. The EasyLog USB software enables quick configuration and data download via the USB port.

Supplied with batteries, two K-type thermocouples, and a magnetic wall mount the EL-GFX-DTC is a popular thermocouple data logger.

You can also view some of the resources of the EL-GFX-DTC.


Measurement Range K Type (provided)0 to +200°C (+32 to +392°F)
Measurement Range K Type-200 to +1,350°C (-328 to +2,462°F)
Measurement Range J Type
-200 to +1,190°C (-328 to +2,174°F)
Measurement Range T Type
-200 to +390°C (-328 to +734°F)
Accuracy (thermocouple error not included)
±1°C (±2°F)
Operating Temperature
-10 to +40°C (+14 to +104°F)
Logging Rate
User selectable between 2 seconds and 1 hour
Calibration Certificate
Available Seperately


EL-GFX-DTC Dual Channel Thermocouple data logger is suitable for a wide variety of applications. These include Food Temperature Monitoring and Facilities Management.
